Forged DPHA Front Caliper Kit by Wilwood

Wilwoods new DynaPro Honda/Acura Caliper (DPHA) for Honda and Acura models originally equipped with 262mm diameter rotors. These calipers bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels including the EM1 Si 15 wheel.

Designed around Wilwoods proven DynaPro series four piston calipers, the forged billet bodied DPHA caliper delivers high-strength clamping force and positive stopping power. Four stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble free for many more miles.

Calipers work perfectly with the OE master cylinder and ABS functions, and are available with either black or red high-gloss, high-temp, brake fluid resistant sealed powder coat and feature Wilwoods signature logo.

Please Note: Check wheel clearance diagram before purchase. This kit requires spindles from vehicles originally equipped with 262mm (10.32″) diameter rotors

Features

• Direct bolt-on fitment
• Forged billet bodied caliper w/ stainless steel pistons
• High strength clamping force & stopping power
• Balanced pad loading
• Corrosion resistant
• Available in 3 powder coating options

Applications

• *Check wheel clearance diagram before purchase. This kit requires spindles from vehicles originally equipped with 262mm (10.32″) diameter rotors
• 1990-2001 Acura Integra GS
• 1992-2001 Acura Integra GS-R
• 1990-2001 Acura Integra LS
• 1990-1998 Acura Integra RS
• 1997-2001 Acura Integra Type R
• 1986-1990 Acura Legend Base
• 1987-1990 Acura Legend L
• 1987-1990 Acura Legend LS
• 1988-1988 Honda Accord DX
• 1988-1988 Honda Accord LX
• 1988-1989 Honda Accord LXi
• 1989-1989 Honda Accord SEi
• 2001-2012 Honda Civic DX
• 1993-1995 Honda Civic DX, Coupe
• 1994-1995 Honda Civic DX, Sedan
• 2001-2012 Honda Civic EX
• 1993-2000 Honda Civic EX, Coupe
• 1990-2000 Honda Civic EX, Sedan
• 2001-2012 Honda Civic GX
• 2013-2015 Honda Civic HF
• 2001-2005 Honda Civic HX
• 2003-2015 Honda Civic Hybrid
• 2001-2015 Honda Civic LX
• 1994-1996 Honda Civic LX, Sedan
• 2002-2005 Honda Civic Si
• 1999-2000 Honda Civic Si, Coupe
• 1994-1995 Honda Civic Si, Hatchback
• 2002-2003 Honda Civic SiR
• 2007-2013 Honda Fit Base
• 2008-2014 Honda Fit DX
• 2012-2012 Honda Fit DX-A
• 2015-2014 Honda Fit EX
• 2015-2014 Honda Fit EX-L
• 2008-2014 Honda Fit LX
• 2007-2014 Honda Fit Sport
• 2011-2014 Honda Insight Base
• 2010-2014 Honda Insight EX
• 2010-2014 Honda Insight LX
• 1988-1990 Honda Prelude 2.0 S
• 1988-1991 Honda Prelude 2.0 Si

What’s In The Box?

• 1 – Forged DPHA Front Caliper Kit

Warranty

• Wilwood offers no warranty on their products. Click here for more information
